S05-SPA-OP Power:5WThe output voltage:5VOutput current:1.0A

• Descrição do produto
• Avaliações de clientes

Features
Wide range of AC input voltage 90-264VAC

Protections against: short circuit/over current/over voltage

Meets diff. mode 2.5KV surge immunity

Meets energy star level VI & CoC V5 Tier 2 (2016)

Open Board

Electrial Specifications
Input Voltage Range: 90-264VAC
Input Current: 200mA
Output Voltage Range: ±5%
Average Efficiency: Meets energy star level VI & CoC V5 Tier 2 (2016)
MTBF: 100,000 hours at full load at 25℃ ambient, calculated per MIL-HDBK-217
Standby Power: 0.075W
Environmental Parameter
Operation Temp: -10℃ ～ 85℃
Storage Temp: - 40℃ ～ 85℃
Humidity : 5% to 95% non condenising
Saftey Standard
Meets CE(EN60950)
Dimensions
36.1mm (L) ; 36.1m (W) ; 20mm (H)
Applications
Medical device and ITE Equipment
Output data

Model	Voltage （V)	Current (A)	Ripple (mV)	115     230	Av. Eff.  (%)Min
UES05-050100SPA-OP	5.0	1.00	150	Y     Y	73.77



YYY: 001-100 Stands for current  0.01-1.00A
